The Runwell Turntable by Shinola

The Runwell Turntable by Shinola
Reviewed by

Shinola’s first audio product is The Runwell Turntable, designed inside and out for the discriminating audiophile and easy to use by any music enthusiast.
Produced in a limited run of 500 units.

Wow and Flutter: < 0.1% Gain: 35.4DB @ 1KHZ RIAA Conformance Deviation: LESS THAN +/- 0.25DB, 20HZ TO 20 KHZ, EXCLUSIVE OF INFRASONIC FILTER AT 13HZ Input Overload: > 200MV AT 1KHZ
Input Impedance: 47KOHM IN PARELLEL WITH 200PF
Signal-to-noise Ratio exclusive of cartridge intrinsic noise, unweighted: > 82DB
Gain 1kHz MM: 35.4DB (JUMPERS OPEN)
Gain 1kHz MC: 55.1DB (JUMPERS INSTALLED)

Termination impedance, MM gain resistive: 47KOHM, VIA SYNTHETIC COOLED TERMINATION
Equivalent temperature of 47kohm input termination, midband: < 20 DEGREES KELVIN Termination impedance, capacitive: 200PF ON BOARD Termination impedance, MC gain resistive: INSTALLED ON INPUT PADS PER CARTRIDGE REQUIREMENTS EQ characteristic: RIAA STANDARD Infrasonic filter: SECOND-ORDER MAXIMALLY-FLAT, -3DBR AT 13HZ Line-level output resistance: 49.9 OHMS, UNMATED Overload margins: > 32DB AT ANY FREQUENCY FROM 20HZ TO 20KHZ, BASED ON REFERENCE LEVELS OF 5MV RMS AT 1KHZ, 500UV RMS AT 20HZ, 50MV RMS AT 20KHZ
Output noise, MM gain, at various analyzer filter bandwidths and 75 ohm generator Z:
22HZ TO 22KHZ: 22UV RMS
100HZ TO 22KHZ: 12UV RMS
400HZ TO 22KHZ: 8.6UV RMS

Output noise, MC gain, 10 ohm generator Z:
22HZ TO 22KHZ: < 220UV RMS 100HZ TO 22KHZ: < 120UV RMS 400HZ TO 22KHZ: < 86UV RMS Power consumption from mains input, preamp only enabled: < 8W Distortion at noise-versus-distortion inflection point: < 0.001%
